P6101- Панельный промышленный TFT LCD-монитор 10.4″ XGA, 350 nit, резистивный сенсорный экран, VGA, DVI-D, HDMI, IP-65

Информационный листок (англ.), PDF

P6101

10.4" XGA TFT Industrial LCD Monitor

Front Bezel NEMA 4/12 (IP65)-compliant, metal front bezel
LCD Panel 10.4" XGA TFT LCD
Max Colors 16.7M
Active Area (mm) 211.2 x 158.4
Max. Resolution 1024 x 768
Display Mode VGA 640 x 350 (70Hz)
VGA 640 x 480 (60/72/75Hz)
VGA 720 x 400 (70Hz)
SVGA 800 x 600 (60/72/75Hz)
XGA 1024 x 768 (60/72/75Hz)
Pixel Pitch (mm) 0.2063 x 0.2063
Backlight MTBF (hrs) 30,000 hrs
Viewing Angle (H/V) 160_/160_
Response Time 16ms
Contrast Ratio 900 (TYP.)
LCD Brightness (cd/m?) 350 nits
Display Control OSD (on screen display)
I/O Interface 1 x RS-232 or USB for touchscreen version
1 x DVI-D
1 x VGA
1 x HDMI
1 x Screw-type DC power input
Touchscreen Resistive type
Power Adapter Screw-type external AC/DC power adapter
Power Comsumption TBD
Operating Temperature 0_C ~ +50_C (+32_F ~ +122_F)
Dimensions
(W x D x H) 277.5 x 48 x 223.55 mm (10.93" x 1.89" x 8.8")
Weight (net/gross) TBD
Mounting Panel mount
Wall mount
Rack mount
VESA arm
