Norco FWMB-7851 одноплатный компьютер на базе Core 2 Duo / Pentium D (LGA775) с 4 сетевыми портами 10/100/1000 Mбит/c

Недоступно для заказа

Norco FWMB-7851 одноплатный компьютер на базе Core 2 Duo / Pentium D (LGA775) с 4 сетевыми портами 10/100/1000 Mбит/c

-Intel® LGA775 Core 2 Duo/ Pentium-4 /Pentium®D Processor
- 2x 240-Pin DDR 533MHz/667MHzMHz DIMM Memory up to 4GB
- 6x 1000Mbps Ethernet
- 4x RJ45 interface and 2x SFP interface
- Realtek RTL655,HD AUDIO 5.1 CH
- 4x SATA channels with software RAID0,1,5 and 10
- 4x Serial ATA/1x IDE/1x CompactFlash/6x USB2.0/1x LPT/1x PCI/2x COM

Specification:

System
Processor
Intel® LGA775 Core 2 Duo/ Pentium-4 /Pentium-D Processor with FSB 533/800MHz
System Memory 2x 240-pin DIMM, DDR 533/667MHz up to 4GB
Chipset Intel 945G+ ICH7R
I/O Chipset IT8712F
BIOS AMI 4M-bit Flash BIOS
Wake On LAN Yes
Watchdog Timer Generates a time-out system reset
H/W Status Monitoring Supports Power Supply Voltages, Fan Speed and Temperature Monitoring
Expansion Interface 1xPCI
Battery Lithium battery
Power Requirement ATX

Ethernet
Chipset 4x Intel®82573E/V/L, 2x Intel®82572EI
Speed 1000Mbps
Interface 4x RJ45,2x SFP
Bypass Function LAN Port Bypass Function

Display
Chipset Intel ®945G integrated Graphics
Memory Dynamic share 224MB system memory for graphic memory
Resolutions Up to 2048X 1536@32bpp for CRT
VGA 1 x DB15

I/O
Storage 1x IDE,4x Serial ATA, 1xCompactFlash,
Serial Port 2x RS-232
Parallel Port SPP/EPP/ECP mode
USB 6x USB2.0
Keyboard and Mouse 2x Keyboard and Mouse port
Digital I/O Support 16-bit digital I/O (programmable)
IrDA 1x IrDA
Audio Realtek RTL655, Support Line out,Line in,CD-in,Mic-in.

Board Size 252mm×262mm
Operating Temperature 0 +60
Storage Temperature -40 +85
Operating Humidity 0%~90% relative humidity, non-condensing

Packing List
PN#
Description
0042541219 Jumper
0560135019 IDE Cable
1660540020 Keyboard/Mouse Cable
0260560019 Serial port cable
0470120009 SATA Cable
0360250019 USB Cable with shielding
0260280019 Parallel Port Cable
0710350070 Audio Cable
-- Utility CD
-- User's Manual
-- Warranty Card
-- FWMB-7851

Model No. Description

FWMB-7851-V10 Fire Wall board,ATX,LGA 775, Core 2 Duo,DDR II 533/667MHz,VGA,4x Giga Lan,1x PCI Slot,Audio,2x COM,6x USB,1x IDE,1x LPT,1x CF.Ver1.0

FWMB-7851-V10-1 Fire Wall board,ATX,LGA 775,Core 2 Duo,DDR II 533/667MHz,VGA,4Giga Lan+2 SFP(Fiber Channel Supported),1x PCI Slot,Audio,2x COM,6x USB,1x IDE,1x LPT,1x CF.Ver1.0
